Product Description
The Fisher 8560 butterfly valve delivers exceptional performance where it matters most. Engineered for precision control in demanding industrial applications, this high-performance valve features bubble-tight sealing and ultra-low leakage rates that meet the strictest requirements. Its robust construction ensures reliable operation in critical processes across oil & gas, chemical, and power generation industries. Whether handling hazardous media or high-pressure steam systems, the 8560 provides the dependable shut-off and precise flow control that engineers trust for their most challenging applications. This valve combines proven reliability with industry-leading sealing technology to keep your operations running smoothly.
Specifications
| Specifications | Details |
|---|---|
| Certifications | PED, CRN, Fugitive Emission, NACE, ATEX, CUTR, Fire Safe |
| Critical Service | General Service |
| Flow Characteristics | Linear |
| Material | Carbon Steel, Stainless, Alloy |
| Operating Temperature | Standard Temperature, High Temperature |
| Power Source | Electric, Hydraulic, Pneumatic, Lever, Gear, Electro-Hydraulic |
| Pressure Class | ASME |
| Process Connection Type | Flanged, Single Flanged, Lugged |
| Seat / Seal Type | Metal, Soft |
| Shutoff Class | Class IV (FCI 70-2), Class VI (FCI 70-2) |
| Standards | B16.34 |
| Stem | Live Loaded, Adjustable Packing |
| Valve Size | NPS 3, NPS 4, NPS 6, NPS 8, NPS 10, NPS 12 |
| Valve Size Standard | NPS |
| Other Configurations | Contact your local Emerson business partner or sales office to learn about additional specifications or options for this product. |
Features
- Eccentric Disc Design：Features an offset disc structure that delivers near-linear flow characteristics. With just a 90° rotation, it enables precise throttling or shut-off control for simple operation and accurate response.
- Critical Service Adaptability：Offers sour service trim and bolting materials fully compliant with NACE MR0175-2002 standards, ideal for corrosive media containing H₂S and other aggressive compounds.
- Eco-Friendly Sealing System：Optional ENVIRO-SEAL packing system provides superior sealing performance, maintaining fugitive emissions below the EPA 100ppm threshold to meet environmental regulations.
- Intrinsically Safe Construction：Standard conductive packing ensures electrical continuity for safe and reliable operation in hazardous areas.
JCSCMRO – Your Trusted Partner for Fisher 8560 Valves,That’s why we’re proud to supply genuine Fisher 8560 High Performance Butterfly Valves – the same quality you expect from Emerson, but with the added benefits of competitive pricing and faster delivery from our well-stocked inventory. Whether you need standard configurations or custom solutions, our team ensures you get the right valve for your application without unnecessary delays. And because we know equipment doesn’t stop at delivery, our after-sales support team is always ready to assist with technical questions or service needs. Let’s discuss how we can streamline your valve supply chain – drop us a line today and we’ll provide a customized quote within 24 hours.
